5000sqm Prefabricated Steel Structure Workshop For Industrial Use
| MOQ: | 1000 sqm |
| Price: | USD 40-60 / sqm |
| Standard Packaging: | Packed on steel pallet with fixture and loaded into 40'HQ/OT |
| Delivery Period: | 6 weeks after shop drawing get approval |
| Payment Method: | T/T,L/C |
| Supply Capacity: | 100,000 sqm / month |
Detail Information
Place of Origin
Shandong, China
Brand Name
TSIN
Certification
ISO, CE, SGS
Model Number
TSIN-PH-workshop05
Document
Application Fields:
Warehouse， Multi-building， Workshops&plants ,Office ,School
Frame Type::
Portal Frame
Design Parameter::
Wind Load,Snow Load And Earthquake
Frame Surface:
Two Lays Of Anti-rust Painting Or Hot Dip Galvanized
Structure Usage:
Up To 45 Years
Window:
Aluminiumn Alloy Window/ PVC Window/ Sandwich Panel Window/louvers
Highlight:
5000sqm Steel Structure Workshop
,Prefabricated Steel Structure Workshop
,Industrial prefab agricultural buildings
Product Description
5000sqm Prefabricated Steel Structure Workshop For Industrial Use
Product Attributes
| Application Fields | Warehouse, Multi-building, Workshops & plants, Office, School |
|---|---|
| Frame Type | Portal Frame |
| Design Parameter | Wind Load, Snow Load And Earthquake |
| Frame Surface | Two layers of Anti-rust Painting or Hot Dip Galvanized |
| Structure Usage | Up to 45 years |
| Window | Aluminium Alloy Window/ PVC Window/ Sandwich Panel Window/louvers |
Product Description
Steel structure workshops & plants are industrial storage facilities built with steel as the primary structural material, valued for their strength, versatility, and cost-effectiveness. They are widely used in industrial manufacturing, agriculture, and retail.
The High Strength Prefabricated Steel Structure Warehouse provides a one-stop solution with fast delivery and experienced installation guidance. The building structure is made of steel, including internal support and external enclosure structure. The steel frame consists of a portal steel frame, including steel columns, steel beams, and bracing. The portal steel frame and the external enclosure structure constitute an enclosed building structure with sufficient strength to withstand severe weather such as strong wind, rain, and snow.
Metal structures are processed (cut, welded, drilled, and painted) in the workshop, then transported to the construction site, often referred to as prefabricated structures. The prefabricated steel structure doesn't need to be welded on-site, and each component only needs to be fixed with bolts, which is convenient and quick to install and saves labor. Five main types of structural components make up the steel frame: tension members, compression members, bending members, combined stress members, and their connections.
Key Performance Characteristics
- High Strength & Durability - Steel's inherent strength allows warehouses to withstand heavy loads (e.g., stacked pallets, machinery) and harsh weather (strong winds, snow, rain) without deformation. It resists rot, pests, and corrosion (when properly treated), ensuring a long service life (typically 30+ years).
- Large Span & Flexible Space - Steel frames support wide, column-free spans (often 20-50 meters), maximizing usable storage area. This flexibility makes it easy to reconfigure layouts for production lines, storage, or workflow reconfigurations as operational needs evolve.
- Quick Construction - Prefabricated steel components (beams, columns, panels) are manufactured off-site and assembled quickly on-site, reducing construction time by 30-50% compared to concrete structures.
- Cost-Efficiency - Lower labor and construction time costs, combined with minimal maintenance needs, make steel warehouses economically viable. They also have good resale value and can be disassembled or relocated if required.
- Sustainability - Steel is 100% recyclable, and many components are made from recycled materials. The long lifespan and energy-efficient insulation options (e.g., insulated panels) further reduce environmental impact.
Key Considerations When Planning a Steel Structure Workshop
- Load-Bearing Requirements: Calculate maximum storage weight (static loads) and dynamic loads (e.g., forklifts) to determine steel grade and frame design.
- Weather Resistance: Choose corrosion-resistant coatings (e.g., galvanization) for humid or coastal areas; design for local snow loads, wind speeds, and rainfall.
- Operational Needs: Ensure sufficient height/clearance for overhead cranes or tall machinery; integrate ventilation, lighting, or insulation (for temperature-sensitive processes).
- Safety & Compliance: Meet fire safety standards (e.g., fireproof coatings, sprinklers) and local building codes; include emergency exits and structural redundancy for high-risk operations.
- Scalability: Design for future expansion (e.g., additional bays) to accommodate growing production demands without major structural overhauls.
Steel structure factories balance strength, flexibility, and efficiency, making them ideal for robust, adaptable industrial operations.
Specification of Steel Structure
| Dimension | Length x width x Eave height, roof slope |
| Type | Single slope, double slope, multi-slope; Single span, double-span, multi-spans; Single floor, double floors, multi-floors |
| Foundation | Concrete and steel foundation bolts |
| Column and beam | Hot rolled or welded H steel Q355B, all high strength bolts connection, straight cross-section or Variable cross-section |
| Horizon and Column Bracing | X or V or other type bracing made from angle steel or steel pipe |
| C or Z purlin | Q235B C/Z section steel with size C160-300 or Z160-300 |
| Roof and wall panel | Single colorful corrugated steel sheet; Sandwich panel with insulation of EPS, Rock wool, glass wool or PU |
| Accessories | Semi-transparent skylight belts, Ventilators, down pipe, gutter, doors, windows, etc |
| Surface treatment | Painting or hot dip galvanized |
| Package | Nude or packed on steel pallet and then loaded into 40'HQ/OT |
| After-sale Service | Online technical support, Onsite Installation, onsite |
Packing and Inspection
At TSIN, we believe that quality is a defining feature of our services. We are committed to providing exceptional quality products and services at all stages of a project lifecycle.
We deploy extensive quality control measures including inspections of all materials prior to and following fabrication. Our highly trained fabrication and welding staff deliver a wide variety of fabrication services designed to meet your specific project requirements.
- Measuring, cutting and welding the steel
- Placing the holes and cleats in the correct position
- Packaging and carefully loading in the right sequence
- Dispatching to site and erecting if required
Company Profile
Qingdao Tsin Steel Structure Construction Technology Co., Ltd. provides integrated solutions for steel structure workshops, warehouses and multi-storey steel buildings, including layout consulting, structural design, fabrication, delivery solutions and installation guidance.
Our production capacity is 2500 tons per month in a 20,000m² workshop area (30,000m² total factory space). We have light/heavy H steel production lines, C/Z purlin production lines, and various types of profiling steel sheet and sandwich panel production lines.
Through skilled staff and continual improvement, we are committed to establishing long-term business relationships with domestic and overseas customers.
Frequently Asked Questions
Q1: Can I have a visit to your factory before the order?
A: Why not? Welcome to visit our factory. You can fly to Qingdao Airport. We will pick you up at the airport. Hotel booking service is available.
Q2: How do we cooperate on certain project?
A: 1. Please send us your project details and your requirements.
2. We will design accordingly, free of charge. Afterwards, please check and confirm whether you like the drawings. If not, we shall get the drawings revised until your confirmation.
3. Pay 30% deposit after signing contract
4. Confirm the details of the design
5. Production and pay the final payment before shipment
6. Supply Installation service online or paid installation
2. We will design accordingly, free of charge. Afterwards, please check and confirm whether you like the drawings. If not, we shall get the drawings revised until your confirmation.
3. Pay 30% deposit after signing contract
4. Confirm the details of the design
5. Production and pay the final payment before shipment
6. Supply Installation service online or paid installation
Q3: What is the price range of steel structures and steel warehouses?
A: The price of steel structures and steel warehouses varies depending on factors such as material quality, size, and design complexity. Generally, the price per square meter can range from tens of dollars to hundreds of dollars. For example, some small-scale simple steel warehouses may start at $19 per square meter, while large-scale, high-quality steel structures may cost $100 or more per square meter.
Q4: Do you supply installation service?
A: We will furnish you the detailed construction drawing and the construction manual which could help you to erect and install the building step by step or even on-site installation services. If needed, our workers and engineers could be sent to the construction site for installation help. The daily salary, accommodation cost, flight cost, food fee will be paid by the BUYER.
Q5: What is the delivery time?
A: Delivery time depends on order quantities and size of building. Generally, the delivery time will be 30 days after receiving deposit. Partial shipment is allowed for big orders.
Q6: What is the anti-rust treatment for steel structure?
A: Anti-rust treatment of steel structure:
- Normal anti-rust paint
- Anti-rust paint with epoxy zinc primer
- Hot-dip galvanization
- Hot-dip galvanization+PU finish
- Stainless steel structure: No.301/304/316 stainless steel structure.
- Normal anti-rust paint
- Anti-rust paint with epoxy zinc primer
- Hot-dip galvanization
- Hot-dip galvanization+PU finish
- Stainless steel structure: No.301/304/316 stainless steel structure.
Q7: How about your quality control?
A: Our products have passed CE EN1090 and ISO9001:2008. We will submit product quality inspection reports to ensure that the materials and manufacturing processes meet high-quality standards.
Q8: Why your price is higher than other suppliers?
A: Our price is higher because we use top steel from major mills in China, smarter designs that balance safety and economy, durable high grade panels/parts (lasting 10-20 years), and avoid cheap shortcuts. A steel structure isn't disposable--cutting costs now means big repairs later. We prioritize long-term value, not low initial prices.
