High Load Bearing Steel Frame Building Dimensionally Stable Steel High Impact
| MOQ: | 800sqm |
| Price: | 30-45$ |
| Standard Packaging: | container |
| Delivery Period: | 10workdays |
| Payment Method: | L/C,T/T |
| Supply Capacity: | 2500ton/month |
Detail Information
Place of Origin
CHINA
Brand Name
Tsinlyne0829
Certification
CE/ISO/SGS
Model Number
Tsin94069000
Document
Structure Type:
Steel Frame Building
Sustainability:
Eco-friendly
Corrosion Resistance:
High
Material:
Steel
Application:
Industrial/Commercial
Size:
Customized
Highlight:
sandwich panel Steel Frame Building
,H shape Steel Frame Building
,Corrosion Resistance prefab metal garage buildings
Product Description
High Load-Bearing Steel Frame Building
Dimensionally stable steel construction with high impact durability for industrial and commercial applications.
Product Attributes
| Attribute | Value |
|---|---|
| Structure Type | Steel Frame Building |
| Sustainability | Eco-friendly |
| Corrosion Resistance | High |
| Material | Steel |
| Application | Industrial/Commercial |
| Size | Customized |
Key Components
- Wall panel: Sandwich panel with color steel two sides and EPS foam filling (width: 1200mm)
- Column: C style steel, H shape
- Floor beam: C style steel (200×40×2.0mm)
- Floor: Light magnesium board (patented)
- Stair: Metal construction
- Roof truss: Angle steel
- Purlin tube metal
- Roof panel: Corrugated sandwich panel with color steel two sides
- Door: Aluminum frame with panel same as wall, with lock
Technical Specifications
- Earthquake resistance: 8 fission intensity
- Wind pressure: <31m/s (about 10 grade)
- Roofing snow load: <80kg/m²
- Roofing live load: 50kg/m²
Key Advantages
Cost-effective construction with quick installation
Short delivery period and easy assembly
Factory-controlled quality assurance
Large span capacity (up to 80 meters)
Excellent seismic performance due to lightweight design
Flexible for expansion or relocation
Aesthetic options with multiple color choices
Long service life exceeding 30 years
Detailed Specifications
- Size: MOQ 10m², customizable width × length × eave height
- Span: 9-180m (single/double/multi slope; single/double/multi span)
- Height: 3-10m
- Slope options: 1/20, 1/10, 1/5, 1/3
- Column distance: 6-9m
- Base: Cement and steel foundation bolts
- Column and beam: Q345(S355JR) or Q235(S235JR) steel, bolted connections
- Bracing: X or V type from angle, round pipe, etc.
- Purlin: C120~C320, Z100~Z200
- Roof/wall panel: Corrugated steel sheet (0.2-1.2mm) or sandwich panel with insulation
Structural Advantages
Steel frame buildings offer exceptional strength and durability, capable of withstanding heavy loads, extreme weather conditions, and resisting fire and pests. The prefabricated components enable rapid on-site assembly, reducing construction time by up to 50% compared to traditional methods. Steel's design flexibility allows for innovative, column-free spaces while being one of the most recycled materials globally (over 90% recycled).
Applications
Our steel frame buildings are ideal for:
- Industrial warehouses and manufacturing facilities
- Distribution centers and storage buildings
- Commercial buildings and retail spaces
- Agricultural structures and airplane hangars
- Multi-story buildings and modular construction
Why Choose Our Steel Structures
- Integrated solutions from design to installation guidance
- Monthly production capacity of 2500 tons
- 30,000m² factory space with advanced CAD and Tekla software
- Experienced project management for international projects
- Proven track record in multiple countries worldwide
Frequently Asked Questions
Are you a trading company or manufacturer?
We have our own steel structure, steel sheet and sandwich panel manufacturing factories. Welcome to visit our facilities.
We have our own steel structure, steel sheet and sandwich panel manufacturing factories. Welcome to visit our facilities.
Can you provide on-site installation service?
We provide detailed installation guides including shop drawings and videos. Our engineers can also visit site for installation guidance when needed.
We provide detailed installation guides including shop drawings and videos. Our engineers can also visit site for installation guidance when needed.
What is the delivery time?
Typically 25-60 days depending on order quantity and complexity.
Typically 25-60 days depending on order quantity and complexity.
How can I get a quotation?
Please contact us with your project requirements for a prompt quotation and technical consultation.
Please contact us with your project requirements for a prompt quotation and technical consultation.
