Long Span Lightweight Steel Frame Metal Buildings Enhanced Thermal Insulation Commercial

• Wall panel: Sandwich panel with color steel two sides and EPS foam filling (width: 1200mm)
• Column: C style steel, H shape
• Floor beam: C style steel, 200×40×2.0mm
• Floor: Light magnesium board (patented)
• Stair: Metal construction
• Roof truss: Angle steel
• Purling tube: Metal construction
• Roof panel: Corrugated sandwich panel with color steel two sides
• Door: Aluminum frame with panel same as wall, with lock

Note: Components may vary based on specific project requirements.

• Earthquake resistance: 8 fission intensity
• Wind pressure: <31m/s (about grade 10)
• Roofing snow load: <80kg/m²
• Roofing live load: 50kg/m²

For custom design projects, please provide:

• Rain load requirements
• Live load specifications
• Snow load calculations
• Wind load parameters
• Crane requirements (if applicable)
• Building dimensions (length, width, height)

• Size: MOQ is 10m², customizable width × length × eave height with various roof slopes
• Span: 9-180m (single slope, double slope, multi-slope options)
• Height: 3-10m
• Slope options: 1/20, 1/10, 1/5, 1/3
• Column distance: 6-9m
• Base: Cement and steel foundation bolts
• Materials: Q345(S355JR) or Q235(S235JR) steel with bolt connections

Steel frame buildings offer exceptional strength and durability, capable of withstanding heavy loads and extreme weather conditions including earthquakes and hurricanes. The prefabricated components enable rapid on-site assembly, reducing construction time by up to 50% compared to traditional methods.

Design flexibility allows for innovative, column-free spaces from expansive warehouses to complex structures. With over 90% recycled material content and energy-efficient design options, these buildings meet sustainability goals while offering long-term cost-effectiveness through durability and low maintenance.
