Fire Retardant Steel Alloy Steel Frame Building 100% Recyclable Steel Material Warehouse
| MOQ: | 800sqm |
| Price: | 30-45$ |
| Standard Packaging: | container |
| Delivery Period: | 10workdays |
| Payment Method: | L/C,T/T |
| Supply Capacity: | 2500ton/month |
Fire Retardant Steel Frame Building
,H shape Steel Frame Building
,Warehouse steel frame construction
| Attribute | Value |
|---|---|
| Structure Type | Steel Frame Building |
| Sustainability | Eco-friendly |
| Corrosion Resistance | High |
| Material | Steel |
| Application | Industrial/Commercial |
| Size | Customized |
- Wall panel: Sandwich panel with color steel two sides and EPS foam filling (width: 1200mm)
- Column: C style steel, H shape
- Floor beam: C style steel (200×40×2.0mm)
- Floor: Light magnesium board (patented)
- Stair: Metal construction
- Roof truss: Angle steel
- Purlin tube metal
- Roof panel: Corrugated sandwich panel with color steel two sides
- Door: Aluminum frame with panel same as wall, with lock
- Earthquake resistance: 8 fission intensity
- Wind pressure: <31m/s (about 10 grade)
- Roofing snow load: <80kg/m²
- Roofing live load: 50kg/m²
- Cost-effective construction with quick installation
- Short delivery period and easy assembly
- Factory-controlled quality assurance
- Large span capacity (up to 80 meters)
- Excellent seismic performance due to lightweight design
- Flexible for expansion or relocation
- Aesthetic options with multiple color choices
- Long service life exceeding 30 years
- Size: MOQ 10m², customizable width × length × eave height
- Span: 9-180m (single/double/multi slope; single/double/multi span)
- Height: 3-10m
- Slope options: 1/20, 1/10, 1/5, 1/3
- Column distance: 6-9m
- Base: Cement and steel foundation bolts
- Column and beam: Q345(S355JR) or Q235(S235JR) steel, bolted connections
- Bracing: X or V type from angle, round pipe, etc.
- Purlin: C120~C320, Z100~Z200
- Roof/wall panel: Corrugated steel sheet (0.2-1.2mm) or sandwich panel with insulation
Steel frame buildings offer exceptional strength and durability, capable of withstanding heavy loads, extreme weather conditions, and resisting fire and pests. The prefabricated components enable rapid on-site assembly, reducing construction time by up to 50% compared to traditional methods. Steel's design flexibility allows for innovative, column-free spaces while being one of the most recycled materials globally (over 90% recycled).
Our steel frame buildings are ideal for:
- Industrial warehouses and manufacturing facilities
- Distribution centers and storage buildings
- Commercial buildings and retail spaces
- Agricultural structures and airplane hangars
- Multi-story buildings and modular construction
- Integrated solutions from design to installation guidance
- Monthly production capacity of 2500 tons
- 30,000m² factory space with advanced CAD and Tekla software
- Experienced project management for international projects
- Proven track record in multiple countries worldwide
We have our own steel structure, steel sheet and sandwich panel manufacturing factories. Welcome to visit our facilities.
We provide detailed installation guides including shop drawings and videos. Our engineers can also visit site for installation guidance when needed.
Typically 25-60 days depending on order quantity and complexity.
Please contact us with your project requirements for a prompt quotation and technical consultation.
