Warehouse Prefabricated Steel Frame With Portal Frame For Industrial Storage
| MOQ: | 800 sqm |
| Price: | USD 40-60 / sqm |
| Standard Packaging: | Packed on steel pallet with fixture and loaded into 40'HQ/OT |
| Delivery Period: | 6 weeks after shop drawing get approval |
| Payment Method: | T/T,L/C |
| Supply Capacity: | 100,000 sqm / month |
Detail Information
Place of Origin
Shandong, China
Brand Name
TSIN
Certification
ISO, CE, SGS
Model Number
TSIN-PH-warehouse02
Application Fields:
Logistics, Manufacturing, Agriculture, And Retail For Storing Goods, Equipment, Or Raw Materials.
Maximum Roof Load (lb./sq.ft):
20+lb/sq.ft
Frame Type::
Portal Frame
Design Parameter::
Wind Load,Snow Load And Earthquake
Working Scope::
Design,Fabrication, Installation
Life Span::
Around 30~50 Year
Highlight:
Warehouse prefabricated steel frame
,Portal Frame prefabricated steel frame
,Industrial Storage steel frame warehouse construction
Product Description
Modern Designed Steel Structure Warehouse for Large-Scale Plants
Product Attributes
| Application Fields | Logistics, manufacturing, agriculture, and retail for storing goods, equipment, or raw materials |
| Maximum Roof Load | 20+ lb/sq.ft |
| Frame Type | Portal Frame |
| Design Parameter | Wind Load, Snow Load And Earthquake |
| Working Scope | Design, Fabrication, Installation |
| Life Span | 30-50 Years |
Product Overview
Steel structure warehouses are industrial storage facilities built with steel as the primary structural material, valued for their strength, versatility, and cost-effectiveness. Our high-strength prefabricated steel structure warehouse offers a complete solution with fast delivery and expert installation guidance.
Specifications
| Dimension | Length × width × eave height, roof slope |
| Type | Single slope, double slope, multi-slope Single span, double-span, multi-spans Single floor, double floors, multi-floors |
| Foundation | Concrete and steel foundation bolts |
| Column and Beam | Hot rolled or welded H steel Q355B, all high strength bolts connection |
| Bracing | X or V type bracing made from angle steel or steel pipe |
| Purlin | Q235B C/Z section steel with size C160-300 or Z160-300 |
| Roof and Wall Panel | Single colorful corrugated steel sheet or sandwich panel with insulation |
| Surface Treatment | Painting or hot dip galvanized |
Key Features
- High Strength & Durability: Withstands heavy loads and harsh weather conditions with a service life of 30+ years
- Large Span & Flexible Space: Supports wide, column-free spans up to 50 meters for maximum usable area
- Cost-Efficiency: Lower construction and maintenance costs with good resale value
- Sustainability: Made from recyclable materials with energy-efficient insulation options
- Quick Construction: Prefabricated components reduce construction time by 30-50%
Quality Control
We implement rigorous quality control measures including material inspections before and after fabrication. Our skilled team ensures precision in:
- Measuring, cutting and welding the steel
- Precise placement of holes and cleats
- Careful packaging and loading sequence
- On-site erection when required
Frequently Asked Questions
Q: Can I visit your factory before ordering?
A: Yes, we welcome factory visits. We can arrange airport pickup and hotel booking services.
Q: What is your quality certification?
A: Our products meet CE EN1090 and ISO9001:2008 standards with comprehensive quality inspection reports.
Q: Why is your price higher than competitors?
A: We use premium steel from major mills, smarter designs, durable components, and avoid cost-cutting measures that compromise long-term value.
About Our Company
Qingdao Tsin Steel Structure Construction Technology Co., Ltd. provides integrated solutions for steel structure projects including design, fabrication, and installation. With a 20,000m² workshop and monthly production capacity of 2,500 tons, we serve domestic and international clients with high-quality steel structures.
